Touring Superleggera presents the Disco Volante production model

Following the introduction of the full-scale styling model in 2012, Touring Superleggera is proud to present the first production model of the iconic Disco Volante at the 2013 Geneva Motor Show. As from now, the Disco Volante will be available to the discerning customer.

After the striking successes in the recent Geneva shows, the Disco Volante is another testimony of Touring's capability as a creator and manufacturer of bespoke-designed cars coach built in very limited runs to world class quality standards.

In just under a year’s time, the Disco Volante has developed from a prototype to a production model; ready to be enjoyed by a clientele appreciating its unique combination of craftsmanship, quality, innovative design and automotive history. Among them will be collectors, sporting drivers and design aficionados.

The Disco Volante is a two-seater Gran Turismo. It is based on the Alfa Romeo 8C Competizione coupé with its front-central mounted 4.7 litre V8 engine and a transaxle rear drive with unmodified specifications. Each unit, of which the construction requires 4,000 hours of manual work, will be built only on demand.

History

The lightweight and ultra-aerodynamic Alfa Romeo C52 'Disco Volante' was considered a design icon almost right from the start, when it saw the light of day in 1952. The briefing at Carrozzeria Touring in that year mentioned the need for a shape that was ‘insensitive to wind’.

The unique basic design was even registered as ‘design patent’. Using Alfa Romeo 1900 C elements, the car received a new tubular chassis, and a lightweight, striking and efficient aluminium body.

Initially aimed at sports car racing, the C52 Disco Volante is one of the best examples to illustrate the credo of Touring’s founder Felice Bianchi Anderloni “Il peso è il nemico, la resistenza dell'aria è l'ostacolo" (weight is the enemy, air resistance the obstacle).

Exterior Design

The present Disco Volante celebrates the myth of the 1952 style icon. The new design briefing required to blend ingredients as innovation, emotion and aerodynamic properties into a timeless and essential shape.

Keywords are: bold, innovative, refreshing, daring.

During the development stage, Head of Design Louis de Fabribeckers and his team cooperated with the engineers on an almost daily basis. "We focused on the preservation of the design essence. – says de Fabribeckers – Once the design frozen, we had to understand the manufacturing problems and solve them right away without compromising the design."

Many elements were changed in this stage, like a slightly higher bonnet needed for the engine bay ventilation. Still, the original proportions were retained, so these changes will be hardly noticed. The final result is even more dramatic and impressive than the styling study that was presented last year.

Interior Design

In consistency with the car's design philosophy the interior has a ‘science fiction’ feel to it.

Part of this ‘spaceship’ atmosphere was created by elements like the red LED interior light profiles.

Also, aeronautics has been the inspiration for parts like the dashboard, instruments and seat adjustment lever.

As for the upholstery, leather hides were bespoke manufactured to reproduce the exterior colour shade. These are matched with black Alcantara™.

Of course, personalisation of the interior design to meet customer’s preferences is part of the offer, in line with Touring's personal commissioning philosophy.

Rolling Chassis

The Alfa Romeo 8C Competizione chassis was chosen for its light and rigid structure and its outstanding dynamic properties. Therefore it forms the perfect basis for the coach-built bodywork of the Disco Volante, integrally conserving the rolling chassis and drive train.

The Alfa Romeo 8C’s steel space-frame and other structural elements were retained to guarantee torsion stiffness, high performance and the quality standard. The frame members and the central carbon cell remained unchanged. Elements of the underpinning and the body, such as the engine bay and firewall, the windscreen and cowl, the a-pillar and the locks and hinges have been retained too, just as the dashboard and instruments, the pedals and the steering wheel.

Parts like doorframes, the roof frame and the c-pillar have been modified to match with the new shape.

The layout of a front-central mounted engine, a transaxle transmission and rear-wheel drive offers an optimal weight distribution of 49-51% between the front and rear axles. To ensure excellent handling the front and rear double-wishbone suspension scheme is combined with hub carriers of forged aluminium and additional trailing arms for the rear suspension.

The lightweight and compact 4.7 litre V8 engine delivers 450HP and 480Nm peak torque. It is coupled with a six-speed sequential transaxle gearbox with electronic control and paddle-shift gear selection. Together with a limited-slip differential and a state-of-the-art braking system with large diameter, ventilated discs a precise, dynamic and proactive drive is ensured.

The Disco Volante can accelerate from 0 to 100 km/h (0-62 mph) in 4,2 seconds and has a top speed of about 290 km/h (181 mph).

Engineering

All new and modified components of the Disco Volante have been CAD designed. In this process, which covers feasibility, safety, homologation, aerodynamics and structural analysis, the most advanced IT tools and simulation techniques have been used.

Since torsion stiffness and noise reduction are of critical importance, special attention has been paid to the under-body structure and its elements, like the tubular frames supporting the rear wings and bumper, and the roll bar joining the c-pillars. Other complex design issues were the tailgate hinges, the 3d-cambered door window, and the front wheel covers.

The Disco Volante was then submitted to a CFD aerodynamic study to enhance the airflow and ensure optimal downforce in the rear section. After that, FEM calculations were run to assess resistance and rigidity of all parts subject to homologation.

Manufacturing Process

Touring Superleggera is synonymous with the manufacture of lightweight bodywork. The weight advantage of aluminium is one of the assets of Touring Superleggera's construction methods. Nowadays however, the craft of hand-beating aluminium panels is combined with the use of carbon fibre reinforced plastic (CFRP). For the Disco Volante, Touring decided to use this combination of aluminium and CFRP. This has been the result of a study conducted to define optimal use of materials for the bodywork in terms of weight, resistance, precision, finish and quality, and ease of repair in case of damage.

The CFRP is used for specific components like the front bumper and grille, the bonnet, the skirts, the boot lid and the integrated rear-window frame. The bonnet and the boot lid are sandwich-built with Nomex filler in-between to obtain a better stiffness/weight ratio and to dampen vibration and noise.

The aluminium panels are hand-beaten using an epoxy mould. Since the inner frames of most parts of the bodywork are made of CFRP, this requires gluing of aluminium on carbon fibre. This technique adds to the rigidity as the glue has structural properties.

The body panels are pre-assembled on a laser measurement platform using a jig. This ensures that the strict tolerance required is respected. After adjustment, the panels are either welded or glued. The body-in-white is then used to preassemble and fit all trim components, brightware and moulding.

To ensure constant and repeatable quality, the entire production process is documented and digitally logged. Like in series production, there is a quantified manufacturing cycle and a Bill of Materials. Tolerances, measurements and other quality standards are quantified.

Quality Assurance

The quality control process includes static as well as dynamic test runs before the car is signed off. The static-test protocol requires compliance to high standards in interstice and surface alignment, paint and coating quality, interior trim and assembly.

A functionality test is run in a climatic chamber. The dynamic test takes place on the proving ground. Beside routine checks on absence of creak, rattle and other noise, it concentrates on handling, braking and all other functionalities. It includes high-speed runs, cornering and other handling tests on several types of surfaces.

Type Approval

The Disco Volante has received EU type-approval under the EU-Directive 2007/46 EC for small series.

Price and Availability

The price of the Disco Volante is on demand.

Touring Superleggera delivers the complete car in six months after the Alfa Romeo 8C is made available.

All Touring-produced or modified parts have a two-year unlimited-mileage warranty, subject to the usual industry terms. Alfa Romeo dealers are qualified for maintenance and service of the technical components, while Touring supplies them repair instructions and parts for the Touring-designed components and systems.

Sales enquiries can be addressed to the factory in Milan.

TECHNICAL DATA

Dimensions

Length: 4,620 mm

Width: 2,032 mm

Height: 1,309 mm

Wheelbase: 2,640 mm

Track front/back: 1,591/1,589 mm

Boot volume: 142 l

Fuel tank capacity: 88 l

Engine

Cylinders / type: 8 / V  90°

Cubic capacity: 4,691 cm³

Nominal output: 331 kW / 450 CV @ 7,000 rpm

Max torque: 480 Nm @ 4750 rpm

Emission level: Euro 5

Fuel consumption, EU drive cycle

Urban: 23,60 l/100 km

Extra-Urban: 11,40 l/100 km

Combined:  15,80  l/100 km

CO2 emissions (combined): 377 g/km

Driveline

Rear wheel drive

6-speed, electroactuated sequential gearbox with paddle-shift control and automatic mode.

Limited slip differential

Wheels

Tires: Pirelli PZero Rosso, front 245/35 ZR20, rear 285/35 ZR20

Wheel type: Aluminium forged wheels

PERFORMANCE

Top speed (est.): 292 km/h

Acceleration (est.) 0-100 km/h: 4.2 s

SOURCE: Touring Superleggera

The Disco Volante 2012, designed as a two-seater coupé with front-central engine and transaxle drivetrain, is presented in Geneva in the form of a full scale style model.

The car will be produced as a very limited series for discerning customers: collectors, sporting drivers and design aficionados with appreciation for a tailor-made car based on individual passion and taste.

There exist very few models that rouse fascination like the Alfa Romeo C52 'Disco Volante'. The briefing at Carrozzeria Touring in 1952 mentioned the need for a shape that was ‘insensitive to wind’. The unique basic design, featuring an oval cross section, evolved in different versions, and was even registered as ‘design patent’.

Using Alfa Romeo 1900 C elements, the car received a new aluminium crankcase, a new tubular chassis, and a very light, striking and efficient aluminium body.

Initially aimed at races in the Sport category, the C52 Disco Volante soon reached the status of design icon. It is one of the most important models in the history of Touring, so innovative that it influenced the automotive design for decades. It also is one of the best examples to illustrate the credo of Touring’s founder Felice Bianchi Anderloni “Il peso è il nemico, la resistenza dell'aria è l'ostacolo" (weight is the enemy, air resistance the obstacle).

So significant is the Disco Volante in the history of automobile design, that Alfa Romeo has chosen this Touring design to celebrate its own 100th anniversary with a bronze sculpture now exhibited in Milan.

Design

The Disco Volante 2012 design briefing required to blend ingredients as innovation, emotion and aerodynamic properties into a timeless and essential shape. The design language is that of a sports berlinetta by Touring, in this case extrovert, clearly pronounced, and tempting.

The integrated front bonnet and wings result in a dramatic monolithic frontal area, while the pronounced muscular rear end treatment leaves no doubts about the car’s intentions. The overall teardrop shape reflects classic volumes with respect for aerodynamic values.

Hints to the past can be found in subtle details, when aesthetical solutions were judged to be congruent with the new design. These include the pronounced waist line underlined by the aluminium profile, the partly covered front wheels, and the prolonged lines of the rear section ending with round shaped tail lights..

The final result is a rear-oriented design, with an extended rear overhang, a retracted greenhouse, and a limited front overhang. It combines power and elegance, integrating a balance between potent and fluid lines and the use of refined proportions in the best Touring tradition.

Rolling Chassis

The hard points of the Disco Volante 2012 are dictated by the Alfa Romeo 8C Competizione chassis, chosen for its light and rigid structure and the outstanding dynamic properties. It forms the perfect basis to receive the totally new, coach built bodywork conserving integrally the rolling chassis and drivetrain.

The front-central engine, transaxle transmission and rear wheel drive layout offers an optimal weight distribution of 49-51% between the front and rear axles.

The steel space-frame is engineered for weight reduction and improved torsional stiffness.

Further feature for top class handling is the front and rear double-wishbone suspension scheme combined with hub carriers of forged aluminium, and additional trailing arms for the rear suspension.

The light and compact V8 engine with 4.7 litre displacement delivers 450 PS and 470Nm peak torque. It is coupled to a 6-speed sequential transaxle gearbox with electronic control and paddle-shift gear selection. A limited slip differential and a state-of-the-art brake system with large diameter, ventilated discs complete the package to endorse precise, dynamic and proactive drive.

The Disco Volante 2012 is a tribute to the best Italian sports car philosophy: refined mechanics dressed with light and exciting bodywork.

Manufacturing Process

Prior to any construction phase at Touring, every new component is CAD designed and documented. The meticulous engineering programme covers feasibility, safety, homologation, aerodynamics and structural analysis. In this process, the most advanced IT tools and simulation techniques are used. Special attention is paid to the underbody structure, a critical factor for quality, torsional stiffness and noise reduction.

Touring has preserved and developed the use of hand-beaten aluminium panels. Today, this traditional way of shaping body parts responds not only to the design requirements, but also to the strictest precision standard.

The weight advantage of aluminium is one of the assets of Touring Superleggera's construction methods. However, carbon fibre is used for specific components such as bumpers and a number of substructures for further weight saving and strength gains.

The entire manufacturing process is fully documented and digitally logged, to guarantee consistent quality levels and accurate reproduction.

3-dimensional reference and measurement tools are used to ensure the highest precision in the assembly stage. Many key detail components and ornaments are entirely manufactured by hand.

The original 8C interior is basically maintained, but modified and upgraded according to the personal preferences and taste of the customer – as an exponent of Touring’s automotive tailoring philosophy.

Each unit requires more than 4,000 hours of highly skilled artisan and engineer work to be completed.

The delivery time for a Disco Volante 2012 is eight months after the reception of the donor vehicle.

Dimensions

Length: 4,613 mm

Width: 2,020 mm

Height: 1,335 mm

Wheelbase: 2,696 mm

Track front / back:

1,591 mm / 1,589 mm

Boot volume: ca. 200 l

Fuel tank capacity: 88 l

Engine

Cylinders / type: 8 / V  90°

Cubic: 4,691 cm³

Nominal output: 335.6 kW / 450 CV @7,000

Max torque: 470 Nm @ 4750 rpm

Emission standard: Euro 5

Driveline: 6-speed, electroactuated sequential gearbox with paddle-shift control and automatic mode.

Limited slip differential.

Wheels

Tires: Pirelli PZero Rosso,

front: 265/35 ZR20

rear: 285 / 35 ZR20

Wheel type: Aluminium forged wheels

Performance

Top speed (est.): 292 km/h

Acceleration (est.) 0-100 km/h: 4.2 s

SOURCE: Touring Superleggera
